BRANCH CONNECTOR GR 2206-8031
WAGO
Art.-no. WS1939580
EAN 4066966185805
-
Show availability at another Center
In order to check the stock in a Würth Elektro branch, please log in.
If you have any questions, please call our service hotline at +358 10 308 4700.
Do you want to register as an Online Shop user? Please go to the registration page.
Exclusively for trade customers
With registration you can access the Würth Elektro online shop selection.
Product information
Datasheets(X)
 | |
Connectable conductor cross section fine-strand without cable end sleeve | 0.5-10 mm² |
Connectable conductor cross section solid-core | 0.5-10 mm² |
Connectable conductor cross section multi-wired | 0.5-10 mm² |
Rated current In | 41 A |
Rated voltage | 800 V |
Type of electrical connection 1 | Spring clamp connection |
Type of electrical connection 2 | Spring clamp connection |
Number of levels | 1 |
Number of clamp positions per level | 7 |
Mounting method | DIN rail (top hat rail) 35 mm |
Material insulation body | Thermoplastic |
Width | 9 mm |
Height | 0 mm |
Colour | Grey |
E-number Finland | 1939580 |
Brand | WAGO |
