Installation side connection model

3-phase

Voltage type (supply voltage)

AC

Input voltage

400-400 V

Frequency

50/60 Hz

Nominal connection power

22 kW

Max. output current DC

0 A

Output voltage AC 50 Hz

400-400 V

Output voltage AC 60 Hz

400-400 V

Max. output current AC 50 Hz

32 A

Max. output current AC 60 Hz

32 A

Number of charging units

1

Max. power per charging point

22 kW

Suitable for floor mounting

No

Suitable for wall mounting

Yes

Portable

No

Width

198 mm

Height

201 mm

Depth

99 mm

Number of vehicle connectors Type 2

1

With house connection box

No

With surge protection module

No

Length of charging cable

5 m

Charging cable permanently lockable at charging device

Yes

DC residual current detection

Yes

Contactor welding detection

No

With miniature circuit breaker (MCB)

No

Network-enabled as a master

Yes

Network-enabled as an extender

Yes

Networkable via LAN

No

Networkable via Wi-Fi

Yes

Mobile communications standard 4G (LTE)

No

Mobile communications standard 5G

No

With energy meter

No

With key switch

No

With built-in RFID card reader

No

NFC (Near Field Communication)

No

Static load management integrated

Yes

Suitable for dynamic load management

Yes

OpenChargePointProtocoll (OCPP) version

2.0

Plug and charge (ISO 15118)

No

With display

No

Housing material

Plastic

Degree of protection (IP)

IP55

Impact strength

IK10

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

No

Operation and configuration by app

Yes

Export of charging logs

Yes

Connectable conductor cross section

13-13 mm²

Backend included

Yes

With MID compliant energy meter

No

Calibration law compliant

No

E-number Finland

3503079
