Installation side connection model

3-phase

Input voltage

400-400 V

Frequency

50/60 Hz

Nominal connection power

11 kW

Number of charging units

1

Max. power per charging point

11 kW

Width

244 mm

Height

342 mm

Depth

107 mm

Number of vehicle connectors Type 2

1

With house connection box

Yes

Length of charging cable

7 m

Charging cable permanently lockable at charging device

No

DC residual current detection

Yes

Contactor welding detection

No

With miniature circuit breaker (MCB)

No

Network-enabled as a master

No

Network-enabled as an extender

No

Networkable via LAN

Yes

Networkable via Wi-Fi

Yes

Mobile communications standard 5G

No

With energy meter

No

With key switch

No

With built-in RFID card reader

No

NFC (Near Field Communication)

No

Static load management integrated

No

Suitable for dynamic load management

Yes

OpenChargePointProtocoll (OCPP) version

1.6

Plug and charge (ISO 15118)

No

With display

No

Housing material

Plastic

Degree of protection (IP)

IP55

Impact strength

IK10

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

No

Operation and configuration by app

Yes

Export of charging logs

Yes

With MID compliant energy meter

No

E-number Finland

3505064
