Conical light post straight B
CONICAL POLE B108SK
Art.-no. WS4607812
EAN 6410046078125
With registration you can access the Würth Elektro online shop selection.
Tehomet's conical columns offer a modern solution for street and road lighting needs. The taper of the light post ensures an optimal ratio between the column's load capacity and appearance. Standard compliant conical light posts have a base cone that facilitates installation and centering of the post on the prefabricated concrete base and evenly transfers loads from steel to concrete. Seamless conical frame ensure a visually flawless solution, especially when the columns are painted or coated with the Plascoat method. The simple elegant post frame for a variety of light post configurations with a variety of luminaire and arm options.
Datasheets(X)
 | |
Stepped shape | No |
Top end diameter | 60 mm |
Diameter at base | 163 mm |
Wall thickness | 3 mm |
Material | Steel |
Surface protection | Galvanized |
Light centre height | 8 m |
Mounting arm length | 0 mm |
With base plate | No |
Supporting bracket | None |
E-number Finland | 4607812 |
