Plastic enclosure TK PC
ENCLOSURE TK PS 1818-9-M IP66 GR
SPELSBERG
With registration you can access the Würth Elektro online shop selection.
Empty enclosure. Ingress protection IP66/IK07, Polycarbonate.
Internal fixing points. For installations in industrial environments and sheltered outdoor areas.
Certified UL (UL 508 & CSA C22.2 No. 14-13, UL 50 & CSA 22.2 No. 94.1-7 & UL 50E & CSA C22.2 No. 94.2-7), DLG (ammonia resistance), Ui=690V AC, Ui=1000V DC
Datasheets(X)
 | |
Width | 182 mm |
Height | 180 mm |
Depth | 90 mm |
Material | Plastic |
Material quality | Other |
Surface finishing | Untreated |
Colour | Grey |
RAL-number | 7035 |
Freestanding | No |
Floor standing wall model | No |
Suitable for wall mounting | Yes |
Corner model | No |
Intermediate mounting | No |
Couplable | No |
With mounting plate | No |
Mounting plate depth-adjustable | No |
Suitable for wall built-in | No |
Pole fastening | Yes |
Number of doors | 0 |
Number of locks | 0 |
Suitable for metrical mounting | Yes |
Pitched roof | No |
EMC-version | No |
With glazed door | No |
With ventilation door | No |
With rear door | No |
Impact strength | IK07 |
Degree of protection (IP) | IP66 |
Thermal dissipation (Delta T = 20 K) according to IEC/TR 60890 | 8.8 W |
E-number Finland | 3429741 |
Brand | SPELSBERG |
