Floodlight IP55 Floodlight PFM Photocell GEN4
FLOODLIGHT FL SYM S 133W/840 20000lm BK
LEDVANCE
Art.-no. WS4529970
EAN 4099854307041
With registration you can access the Würth Elektro online shop selection.
An advanced LED luminaire that saves up to 90% energy compared to traditional floodlights. The smart daylight sensor automatically turns the luminaire on and off depending on the amount of ambient light, and as an additional feature, you can easily set it to stay on continuously with a light switch.
Breather membrane ensures ventilation while maintaining a high IP rating. The Multi Lumen feature allows you to select the power according to your needs. The robust design, tempered glass and even lighting ensure durability and comfortable lighting, without lighting loss (ULOR 0%) when tilted at 0°.
Datasheets(X)
 | |
Suitable for surface mounting | Yes |
Suitable for built-in mounting | No |
Suitable for wall mounting | Yes |
Suitable for suspended mounting | No |
Suitable for ceiling mounting | No |
Suitable for traverse mounting | No |
Suitable for pedestal/floor mounting | Yes |
Suitable for light-track mounting | No |
Suitable for clamp-mounting | No |
Suitable for low voltage cable system | No |
Adjustability | Swivelling |
With movement sensor | No |
With light sensor | Yes |
Lamp type | LED not exchangeable |
With light source | Yes |
Suitable for number of light sources | 0 |
Lamp holder | None |
Housing material | Aluminium |
Surface protection | Powder coating |
Housing colour | Black |
Surface brushed | No |
Voltage type | AC |
Nominal voltage | 220-240 V |
Type of control gear | Electronic ballast |
With control gear | Yes |
Exchangeable control gear | No |
Dimming 0-10 V | No |
Dimming 1-10 V | No |
Dimming DALI-2 | No |
Dimming DALI | No |
Dimming DMX | No |
Dimming DSI | No |
Dimming potentiometer (integrated) | No |
Dimming LineSwitch | No |
Dimming manufacturer's proprietary system | No |
Dimming mains voltage modulation | No |
Dimming phase cut-off | No |
Dimming phase cut-on | No |
Dimming programmable | No |
Dimming RF | No |
Dimming Sine Wave Reduction | No |
Dimming Touch and Dim | No |
Dimming Zigbee | No |
Dimming with push-button | No |
No dim function | Yes |
Reflector | Matt |
Light distributor | Reflector |
Light sharing | Symmetric |
Light outlet | Direct |
Rated life time L70/B50 at 25 °C | 100000 h |
Constant light output (CLO) | No |
Degree of protection (IP) | IP66 |
Impact strength | IK08 |
Protection class | I |
Rated ambient temperature according to IEC 62722-2-1 | -30-50 °C |
Max. system power | 133 W |
Colour of light | White |
Colour temperature | 4000-4000 K |
Colour rendering index CRI | 80-89 |
Luminous flux | 20000-20000 lm |
Rated luminous flux according to IEC 62722-2-1 | 20000 lm |
Power factor | 0.9 |
Colour of light adjustable | No |
Luminous flux adjustable | No |
Beam angle adjustable | No |
Width | 58 mm |
Height/depth | 376 mm |
Length | 294 mm |
Type of wiring | Ending |
Number of poles | 3 |
Connection type | Push-in clamp |
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | Yes |
Max. number of luminaires per miniature circuit breaker B16 (MCB) | 4 |
Emergency power supply integrated | No |
Luminaire efficacy | 150 lm/W |
Photobiological safety according to EN 62471 | RG1 |
Suitable for workplace according to EN 12464-1 | No |
Covering of the luminaire with thermally insulating material possible | No |
IFTTT support available | Yes |
Colour consistency (McAdam ellipse) | SDCM5 |
Compatible with Apple HomeKit | No |
Compatible with Google Assistant | No |
Compatible with Amazon Alexa | No |
E-number Finland | 4529970 |
Brand | LEDVANCE |
