Suitable for surface mounting

Yes

Suitable for built-in mounting

No

Suitable for wall mounting

Yes

Suitable for suspended mounting

Yes

Suitable for ceiling mounting

No

Suitable for traverse mounting

Yes

Suitable for pedestal/floor mounting

Yes

Suitable for light-track mounting

No

Suitable for clamp-mounting

No

Suitable for low voltage cable system

No

Adjustability

Swivelling

With movement sensor

No

With presence detector

No

With light sensor

No

Lamp type

LED exchangeable

With light source

Yes

Housing material

Aluminium

Surface protection

Powder coating

Housing colour

Grey

Material cover

Glass transparent

Surface brushed

No

Voltage type

DC

Nominal voltage

0-3 V

Nominal current

3750-9000 mA

With control gear

No

Dimmable

No

Exchangeable control gear

No

Dimming 0-10 V

No

Dimming 1-10 V

Yes

Dimming DALI-2

No

Dimming DALI

No

Dimming DMX

Yes

Dimming DSI

No

Dimming potentiometer (integrated)

No

Dimming LineSwitch

No

Dimming manufacturer's proprietary system

No

Dimming mains voltage modulation

No

Dimming phase cut-off (trailing edge)

No

Dimming phase cut-on (leading edge)

No

Dimming programmable

No

Dimming RF

No

Dimming Sine Wave Reduction

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Light distributor

Reflector

Light distribution

Symmetric

Reflector colour

White

Beam angle

> 80° - Extreme wide beam

Light outlet

Direct

Rated lifetime L70/B50 at 25 °C

115000 h

Constant light output (CLO)

No

Degree of protection (IP), front side

IP66

Impact strength

IK08

Protection class according to IEC 61140

I

Rated ambient temperature according to IEC 62722-2-1

-40-50 °C

Max. system power

1800 W

Emergency power supply system

None

Colour of light

White

Colour temperature

4000-4000 K

Colour of light adjustable

No

Colour rendering index CRI

70-79

Rated luminous flux according to IEC 62722-2- 1

273000-273000 lm

Luminous flux adjustable

No

Luminaire efficacy

151-151 lm/W

Power factor

0.94

Beam angle adjustable

No

Length

800 mm

Width

660 mm

Height/depth

171 mm

Type of wiring

Ending

Number of poles

5

Conductor cross section

1.5 mm²

Connectable conductor cross section

1.5-1.5 mm²

Luminaire with limited surface temperature, sign "D" according to EN 60598-2-24

No

Filament test according to IEC 60695-2-11

650 °C - 30 s

Photobiological safety according to EN 62471

RG2

Suitable for workplace according to EN 12464-1

No

Covering of the luminaire with thermally insulating material possible

No

IFTTT support available

No

Colour consistency (McAdam ellipse)

SDCM5

Compatible with Apple HomeKit

No

Operation by Bluetooth

No

Compatible with Google Assistant

No

Compatible with Casambi

No

Compatible with Amazon Alexa

No

E-number Finland

4544195

Brand

LEDVANCE
