Conductor material

Copper

Conductor surface

Bare

Nominal cross section conductor

1.5 mm²

Diameter conductor

1.38 mm

Conductor category

Class 1 = solid

Conductor resistance at 20 °C

12.1

Number of cores

5

Number of power lines

5

Twisted cores

No

Material core insulation

Polyvinyl chloride (PVC)

Core identification according to HD 308 S2

Yes

Core identification

Colour

Core colour

Several

With protective conductor

Yes

Max. permitted conductor temperature

70 °C

Screen

No

Drain wire

No

Protective barrier

None

Armouring/reinforcement

None

Material outer sheath

Polyvinyl chloride (PVC)

Colour outer sheath

White

Cable geometry

Round

Reaction-to-fire according to EN 13501-6: Class

Eca

Reaction-to-fire according to EN 13501-6: Smoke production

None

Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

None

Reaction-to-fire according to EN 13501-6: Acidity

None

Outer diameter approximate

10.4 mm

Min. permitted bending radius, stationary application/permanent installation

124.8 mm

Permitted cable outer temperature after assembling without vibration

-50-70 °C

Nominal voltage U0

300 V

Nominal voltage U

500 V

Shape of conductor

Round

Suitable as installation cable

Yes

Certified for shipboard application

No

Certified as airport lighting cable

No

Weight

195 kg/km

Circuit integrity according to BS 6387 CWZ

No

Circuit integrity according to BS 8491

No

E-number Finland

0422519
