Conductor material

Copper

Conductor surface

Tinned

Nominal cross section conductor

6 mm²

AWG size

Other

Conductor category

Class 5 = flexible

Conductor resistance at 20 °C

3.39 Ohm/km

Shape of conductor

Round

Number of cores

1

Material core insulation

Rubber

Specification core insulation

Rubber - Hard grade Ethylene Propylene Rubber (HEPR)

Core identification according to HD 308 S2

No

Core identification

Colour

Laminated sheath

No

Fibre optic elements

No

With protective conductor

No

Inner semi-conducting layer

No

Outer semi-conducting layer

No

Screen

No

Drain wire

No

Lead sheath

No

Number of pilot/reduced conductors

0

Concentric conductor

None

Nominal cross section concentric conductor

0 mm²

Material outer sheath

Rubber

Specification material outer sheath

Rubber - ethylene-vinyl acetate (EVA)

Colour outer sheath

Red

Cable geometry

Round

Conductive coating

No

Longitudinal water blocking conductors

No

Longitudinal water blocking screen

No

Reaction-to-fire according to EN 13501-6: Class

Dca

Reaction-to-fire according to EN 13501-6: Smoke production

s2

Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

d2

Reaction-to-fire according to EN 13501-6: Acidity

a1

Halogen free according to EN IEC 60754-2

Yes

Low smoke according to EN IEC 61034-2

Yes

Outer diameter approx.

7 mm

Min. permitted bending radius, stationary application/permanent installation

45 mm

Weight

80 kg/km

Max. conductor temperature

90 °C

Permitted cable outer temperature during assembling/handling

-25-40 °C

Permitted cable outer temperature after assembling without vibration

-50-80 °C

Nominal voltage U0

1 kV

Nominal voltage U

1 kV

Suitable as installation cable

Yes

Certified for shipboard application

No

Suitable as medium-voltage cable

No

Suitable as high-voltage cable

No

Certified as airport lighting cable

No

E-number Finland

0403266
