JUNCTION BOX ABOX 025-2,5MM2/W IP66 WT
With registration you can access the Würth Elektro online shop selection.
Datasheets(X)
 | |
Max. conductor cross section | 2.5 mm² |
Equipped with | Push-in clamp |
Shape | Square |
Mounting method | Wall-/ceiling mounting |
Mounting in the soil | No |
Mounting under water | No |
Inlet from the rear | Yes |
Length | 87 mm |
Width | 87 mm |
Depth | 52 mm |
Tackable | No |
Number of inlets | 9 |
Type of housing feed-through | Seal membrane |
Material | Plastic |
Halogen free | Yes |
Surface protection | Untreated |
Colour | White |
Degree of protection (IP) | IP66 |
Degree of protection (NEMA) | Other |
Cover model | None |
Transparent cover | No |
Cover attachment | Screwed |
Castable | No |
With casting compound | No |
Sealable | Yes |
Rated insulation voltage Ui | 450 V |
Circuit integrity | None |
With screening | No |
Weatherproof | Yes |
Operating temperature | -25-55 °C |
Explosion-tested version | No |
For Ex-zone gas | None |
For Ex-Zone dust | None |
E-number Finland | 1622158 |
