Key selector switch Harmony
KEY HANDLE HARMONY 2 POS.
SCHNEIDER ELECTRIC
Art.-no. WS2320262
EAN 3389110887136
With registration you can access the Würth Elektro online shop selection.
Key and head for switch
Fits all Harmony contact blocks
Datasheets(X)
 | |
Number of switch positions | 2 |
Type of control element | Key |
Suitable for illumination | No |
With light source | No |
Colour button | Black |
Hole diameter | 22.5 mm |
Switching function latching | Yes |
Spring-return | No |
Degree of protection (IP) | IP66 |
Degree of protection (NEMA) | 13 |
Number of contacts as normally open contact | 1 |
Number of contacts as normally closed contact | 0 |
Number of contacts as change-over contact | 0 |
Type of electric connection | Screw connection |
With front ring | Yes |
Material front ring | Metal |
Colour front ring | Chrome |
E-number Finland | 2320262 |
Brand | SCHNEIDER ELECTRIC |
