Suitable for light line configuration

Yes

Suitable for workplace according to EN 12464-1

No

Lamp type

LED exchangeable

With light source

Yes

Housing material

Aluminium

Housing colour

White

Voltage type

AC

Nominal voltage

220-240 V

Nominal current

850-850 mA

Type of control gear

LED operating device current-controlled

With control gear

Yes

Exchangeable control gear

Yes

Dimmable

Yes

Dimming phase cut-on (leading edge)

Yes

Light distributor

Diffuser lens/optic/panel

Light distribution

Symmetric

Colour consistency (McAdam ellipse)

SDCM3

Light outlet

Direct/indirect

Direct-/indirect proportion separately controllable

Yes

Energy efficiency class of the light source according to EU regulation 2019/2015

C

Containing product according to 2019/2020/EU

Yes

Rated lifetime L70/B50 at 25 °C

100000 h

Max. number of luminaires per miniature circuit breaker B16 (MCB)

28

Max. number of luminaires per miniature circuit breaker C16 (MCB)

45

Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)

90 %

Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq)

85 %

Degree of protection (IP)

IP20

Protection class according to IEC 61140

I

Luminaire efficacy

133-144 lm/W

Rated luminous flux according to IEC 62722-2- 1

5450-5900 lm

Max. system power

41 W

Colour of light

White

Colour temperature

3000-4000 K

Colour rendering index CRI

90-100

Power factor

0.9

Flickering value Pst LM

0.013

Stroboscope effect value SVM

0.001

Colour of light adjustable

Positions

Luminous flux adjustable

Continuously variable

Beam angle adjustable

Positions

Width

52 mm

Height/depth

78 mm

Length

1201 mm

With suspension

Yes

Pendant length

10-1400 mm

Type of wiring

Suitable for loop-through wiring

Connection type

Push-in clamp

E-number Finland

4158884
