Suitable for wall mounting

Yes

Suitable for suspended mounting

No

Suitable for ceiling mounting

Yes

Suitable for built-in mounting

No

Suitable for surface mounting

Yes

Suitable for light line configuration

No

Suitable for clamp-mounting

No

Lamp type

LED exchangeable

With light source

Yes

Suitable for number of light sources

1

Housing material

Plastic

Housing colour

White

Material cover

Other

Type of grid

None

Voltage type

AC

Nominal voltage

220-240 V

Nominal current

62.5-68.2 mA

Type of control gear

LED operating device current-controlled

With control gear

Yes

Exchangeable control gear

Yes

Dimmable

Yes

Dimming 0-10 V

No

Dimming 1-10 V

No

Dimming DALI

Yes

Dimming DALI-2

Yes

Dimming DMX

No

Dimming DSI

No

Dimming manufacturer's proprietary system

No

Dimming mains voltage modulation

No

Dimming phase cut-off (trailing edge)

No

Dimming phase cut-on (leading edge)

No

Dimming programmable

No

Dimming potentiometer (integrated)

No

Dimming RF

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Light distributor

Diffuser lens/optic/panel

Light distribution

Symmetric

Beam angle

> 80° - Extreme wide beam

Colour consistency (McAdam ellipse)

SDCM3

Light outlet

Indirect

Energy efficiency class of the light source according to EU regulation 2019/2015

D

Containing product according to 2019/2020/EU

Yes

Rated lifetime L70/B50 at 25 °C

100000 h

Degree of protection (IP), rear side

Other

Degree of protection (IP), front side

IP66

Max. number of luminaires per miniature circuit breaker C10 (MCB)

40

Max. number of luminaires per miniature circuit breaker B16 (MCB)

64

Max. number of luminaires per miniature circuit breaker C16 (MCB)

64

Impact strength

IK10

Protection class according to IEC 61140

II

Luminaire with limited surface temperature, sign "D" according to EN 60598-2-24

No

Emergency power supply system

None

Rated ambient temperature according to IEC 62722-2-1

-20-45 °C

Luminous flux in emergency mode

335 lm

Suitable for emergency lighting

No

Emergency function monitoring system

None

With switch

No

With presence detector

No

With movement sensor

No

Movement sensor/presence detector technology

Other

With light sensor

No

Covering of the luminaire with thermally insulating material possible

No

With air slots

No

Filament test according to IEC 60695-2-11

650 °C - 30 s

Luminaire efficacy

130-130 lm/W

Max. system power

13.5 W

Rated luminous flux according to IEC 62722-2- 1

1750-1750 lm

Colour temperature

3000-4000 K

Colour rendering index CRI

80-89

Power factor

0.9

Constant light output (CLO)

No

Width

67 mm

Height/depth

67 mm

Length

67 mm

Outer diameter

220 mm

Type of wiring

Loop-through wiring included

Number of poles

4

Conductor cross section

2.5 mm²

Total harmonic distortion (THD)

12 %

Connection type

Cable

Photobiological safety according to EN 62471

RG0

Connectable conductor cross section

1-2.5 mm²

Colour of light adjustable

Continuously variable

Luminous flux adjustable

Positions

Beam angle adjustable

No

Operation by Bluetooth

No

Compatible with Casambi

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

No

E-number Finland

4579696

Brand

SYLVANIA
