Suitable for suspended mounting

No

Suitable for ceiling mounting

No

Suitable for built-in mounting

No

Suitable for surface mounting

No

Suitable for light line configuration

No

Suitable for workplace according to EN 12464-1

No

Lamp type

LED not exchangeable

With light source

Yes

Suitable for number of light sources

1

Lamp holder

Other

Housing material

Aluminium

Surface protection housing

Lacquered

Housing colour

Anthracite

Material cover

Glass opal

Type of grid

None

Voltage type

AC

Nominal voltage

220-240 V

Type of control gear

LED operating device current-controlled

With control gear

Yes

Exchangeable control gear

Yes

Dimming 0-10 V

No

Dimming 1-10 V

No

Dimming DALI-2

No

Dimming DALI

No

Dimming DMX

No

Dimming DSI

No

Dimming potentiometer (integrated)

No

Dimming manufacturer's proprietary system

No

Dimming mains voltage modulation

No

Dimming phase cut-off (trailing edge)

No

Dimming phase cut-on (leading edge)

No

Dimming programmable

No

Dimming RF

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Light distribution

Asymmetric

Beam angle

Medium beam 21-40°

Colour consistency (McAdam ellipse)

SDCM3

Light outlet

Direct

Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)

94.5 %

Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)

92.2 %

Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq)

88.5 %

Max. number of luminaires per miniature circuit breaker B16 (MCB)

24

Max. number of luminaires per miniature circuit breaker C16 (MCB)

40

Impact strength

IK07

Protection class according to IEC 61140

I

Luminaire with limited surface temperature, sign "D" according to EN 60598-2-24

No

Rated ambient temperature according to IEC 62722-2-1

-20-30 °C

Suitable for emergency lighting

No

With movement sensor

No

With light sensor

No

Covering of the luminaire with thermally insulating material possible

No

With air slots

No

Filament test according to IEC 60695-2-11

None

Suitable for lamp power

23-23 W

Max. system power

23 W

Colour of light

White

Colour temperature

4000-4000 K

Constant light output (CLO)

No

Width

300 mm

Height/depth

100 mm

Length

100 mm

Photobiological safety according to EN 62471

RG0

Colour of light adjustable

No

Luminous flux adjustable

No

Beam angle adjustable

No

Operation by Bluetooth

No

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

IFTTT support available

No

E-number Finland

4532661
