STEINEL

LIGHT RS PRO P2 S IP54 1731lm 4K
STEINEL

Art.-no. WS4114962

EAN 4007841056070

-

Art.-no. WS4114962

-
Quantity
PU
x 1

Show availability at another Center
Exclusively for trade customers

With registration you can access the Würth Elektro online shop selection.

Product information

Würth Elektronik Oy Catalogue

Datasheets(X)

Certificates/ Documents

 |

 |

Suitable for suspended mounting

No

Suitable for ceiling mounting

Yes

Suitable for built-in mounting

No

Suitable for surface mounting

Yes

Suitable for light line configuration

No

Suitable for workplace according to EN 12464-1

No

Lamp type

LED not exchangeable

With light source

Yes

Lamp holder

Other

Housing material

Plastic

Material cover

Plastic, opal

Type of grid

None

Nominal voltage

220-240 V

Type of control gear

LED operating device current-controlled

With control gear

Yes

Dimming 0-10 V

No

Dimming 1-10 V

No

Dimming DMX

No

Dimming DSI

No

Dimming potentiometer (integrated)

No

Dimming manufacturer's proprietary system

No

Dimming mains voltage modulation

No

Dimming phase cut-off (trailing edge)

No

Dimming phase cut-on (leading edge)

No

Dimming RF

No

Dimming Touch and Dim

No

Dimming Zigbee

No

Dimming with push-button

No

Light distribution

Symmetric

Beam angle

Extreme wide beam >80°

Light outlet

Direct

Impact strength

IK03

Protection class according to IEC 61140

II

Luminaire with limited surface temperature, sign "D" according to EN 60598-2-24

No

Rated ambient temperature according to IEC 62722-2-1

-10-40 °C

Suitable for emergency lighting

No

With movement sensor

Yes

Covering of the luminaire with thermally insulating material possible

No

With air slots

No

Filament test according to IEC 60695-2-11

650 °C - 30 s

Suitable for lamp power

15.4-15.4 W

Max. system power

15.4 W

Colour of light

White

Colour temperature

4000-4000 K

Power factor

0.96

Height/depth

110 mm

Length

110 mm

Outer diameter

320 mm

Conductor cross section

2.5 mm²

Connection type

Other

Photobiological safety according to EN 62471

RG1

Operation by Bluetooth

No

E-number Finland

4114962
