Wall luminaire IP65 Sharp Wall Asym
LUMINAI. SHARP WALL ASYM 3100lm 3/4K AN
HIDE-A-LITE
With registration you can access the Würth Elektro online shop selection.
Sharp Wall is a stylishly designed wall luminaire that is perfect for lighting facades.
Available with or without asymmetric light distribution that effectively illuminates both the facade and its front, such as parking areas or entrances.
The luminaire offers selectable luminous flux and colour temperature, which can be easily selected using a DIP switch. The Sharp Wall Asym model is equipped with a replaceable LED light source, which allows for easy maintenance and long-lasting use.
Impact-resistant (IK10) and weather-resistant powder coating make it a durable choice for Nordic conditions. The tiltable head allows you to direct the light from 0-30°.
Datasheets(X)
 | |
Suitable for suspended mounting | No |
Suitable for ceiling mounting | No |
Suitable for surface mounting | Yes |
Lamp type | LED exchangeable |
With light source | Yes |
Suitable for number of light sources | 1 |
Housing material | Aluminium |
Surface protection housing | Powder coating |
Housing colour | Anthracite |
Material cover | Plastic, transparent |
Type of grid | None |
Voltage type | AC |
Nominal voltage | 220-240 V |
Nominal current | 250-750 mA |
Type of control gear | LED operating device current-controlled |
With control gear | Yes |
Exchangeable control gear | Yes |
No dim function | Yes |
Light distributor | Focal lens |
Light sharing | Asymmetric |
Beam angle | Extreme wide beam >80° |
Colour consistency (McAdam ellipse) | SDCM3 |
Light outlet | Direct |
Rated life time L70/B50 at 25 °C | 100000 h |
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) | 84 % |
Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq) | 76 % |
Max. number of luminaires per miniature circuit breaker B16 (MCB) | 19 |
Max. number of luminaires per miniature circuit breaker C16 (MCB) | 32 |
Degree of protection (IP) | IP65 |
Impact strength | IK10 |
Protection class | I |
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
Rated ambient temperature according to IEC 62722-2-1 | -20-50 °C |
Max. system power | 31 |
Luminaire efficacy | 100 lm/W |
Rated luminous flux according to IEC 62722-2-1 | 3100 lm |
Colour of light | White |
Colour temperature | 3000-4000 K |
Flickering value Pst LM | 0.056 |
Colour rendering index CRI | 80-89 |
Power factor | 0.94 |
Stroboscope effect value SVM | 0.012 |
Constant light output (CLO) | No |
Width | 200 mm |
Height/depth | 61 mm |
Length | 450 mm |
Type of wiring | Suitable for through wiring |
Number of poles | 3 |
Conductor cross section | 1.5 mm² |
Connection type | Push-in clamp |
Total harmonic distortion | 9 |
Luminous intensity | 1330 cd |
Colour of light adjustable | Positions |
Luminous flux adjustable | Positions |
Beam angle adjustable | No |
E-number Finland | 4528898 |
Brand | HIDE-A-LITE |
