Wall luminaire IP44, AVR8 eWay

Name: Wall luminaire IP44, AVR8 eWay
Brand: ENSTO
SKU: WS4517010

LUMINAIRE AVR8 IP44 LED 9W/840 PCO AL
ENSTO

Art.-no. WS4517010

EAN 6418677624889

All versions

Wall luminaire IP44, AVR8 eWay

Art.-no. WS4517010

Quantity

x 1

Show availability at another Center

Exclusively for trade customers

With registration you can access the Würth Elektro online shop selection.

Locate Center shop
Login/Register
Call customer service: 010 308 4700

Your feedback for this product

A modern, clean-lined, durable and energy-efficient outdoor lamp for lighting courtyards. The wall-mounted luminaire is well suited for lighting the entrances of apartment buildings as well as the surrounding areas of various industrial halls.

Product information

Würth Elektronik Oy Catalogue

Datasheets(X)

Certificates/ Documents

Suitable for wall mounting	Yes
Suitable for suspended mounting	No
Suitable for ceiling mounting	No
Suitable for built-in mounting	No
Suitable for surface mounting	Yes
Suitable for light line configuration	No
Suitable for workplace according to EN 12464-1	No
Lamp type	LED exchangeable
With light source	Yes
Suitable for number of light sources	1
Housing material	Aluminium
Housing colour	Aluminium
Material cover	Plastic, opal
Type of grid	None
Voltage type	AC
Nominal voltage	230-230 V
Type of control gear	LED operating device voltage-controlled
With control gear	Yes
Dimming 0-10 V	No
Dimming 1-10 V	No
Dimming DALI	No
Dimming DMX	No
Dimming DSI	No
Dimming potentiometer (integrated)	No
Dimming GPRS	No
Dimming LineSwitch	No
Dimming manufacturer's proprietary system	No
Dimming mains voltage modulation	No
Dimming phase cut-off	No
Dimming phase cut-on	No
Dimming programmable	No
Dimming RF	No
Dimming Sine Wave Reduction	No
Dimming Touch and Dim	No
Dimming Zigbee	No
Dimming with push-button	No
Dimming depending on control gear	No
No dim function	Yes
Light sharing	Symmetric
Beam angle	Open beam/diffuse
Light outlet	Direct
Rated life time L70/B50 at 25 °C	100000 h
Rated life time L80/B10 at 25 °C	100000 h
Rated life time L90/B10 at 25 °C	71000 h
Degree of protection (IP)	IP44
Impact strength	IK10
Protection class	I
Suitable for emergency lighting	No
With movement sensor	No
With light sensor	No
Covering of the luminaire with thermally insulating material possible	Yes
With air slots	No
Max. system power	9 W
Rated luminous flux according to IEC 62722-2-1	790 lm
Colour of light	White
Colour temperature	4000-4000 K
Colour rendering index CRI	80-89
E-number Finland	4517010
Brand	ENSTO
