MCCB COMPACT 75kA/690V 3P 125A TMD
SCHNEIDER ELECTRIC
With registration you can access the Würth Elektro online shop selection.
Datasheets(X)
Rated permanent current Iu | 125 A |
Rated voltage | 690-690 V |
Overload release current setting | 87.5-125 A |
Adjustment range undelayed short-circuit release | 1250-1250 A |
Power loss | 28.35 W |
Integrated earth fault protection | No |
Type of electrical connection of main circuit | Screw connection |
Suitable for DIN rail (top hat rail) mounting | No |
DIN rail (top hat rail) mounting optional | Yes |
With switched-off indicator | Yes |
With integrated under voltage release | No |
Number of poles | 3 |
Position of connection for main current circuit | Front side |
Type of control element | Wing knob |
Complete device with protection unit | Yes |
Motor drive integrated | No |
Motor drive optional | Yes |
Degree of protection (IP) | IP40 |
E-number Finland | 3658534 |
Brand | SCHNEIDER ELECTRIC |
