Rated permanent current Iu

16 A

Rated voltage

220-690 V

Rated short-circuit breaking capacity Icu at 400 V, 50 Hz

36 kA

Overload release current setting

11.2-16 A

Adjustment range undelayed short-circuit release

500-500 A

Power loss

9.2 W

Device construction

Built-in device fixed built-in technique

Integrated earth fault protection

No

Type of electrical connection of main circuit

Screw connection

Suitable for DIN rail (top hat rail) mounting

Yes

DIN rail (top hat rail) mounting optional

No

With switched-off indicator

Yes

Number of poles

4

Position of connection for main current circuit

Front side

Type of control element

Wing knob

Complete device with protection unit

Yes

Motor drive integrated

No

Motor drive optional

No

Degree of protection (IP)

IP40

E-number Finland

3658015

Brand

SCHNEIDER ELECTRIC
