Rated permanent current Iu

50 A

Rated voltage

220-440 V

Rated short-circuit breaking capacity Icu at 400 V, 50 Hz

25 kA

Overload release current setting

20-50 A

Adjustment range short-term delayed short-circuit release

30-500 A

Adjustment range undelayed short-circuit release

750-750 A

Power loss

4.8 W

Device construction

Built-in device fixed built-in technique

Integrated earth fault protection

Yes

Type of electrical connection of main circuit

Screw connection

Suitable for DIN rail (top hat rail) mounting

Yes

DIN rail (top hat rail) mounting optional

No

With switched-off indicator

Yes

Number of poles

4

Position of connection for main current circuit

Front side

Type of control element

Wing knob

Complete device with protection unit

Yes

Motor drive integrated

No

Motor drive optional

No

Degree of protection (IP)

IP40

E-number Finland

3658085

Brand

SCHNEIDER ELECTRIC
