MODULAR ENCL. SURF. 18X2M IP40 GW40049BS
With registration you can access the Würth Elektro online shop selection.
Datasheets(X)
 | |
Mounting method | Surface mounted |
Number of rows | 2 |
Width in number of modular spacings | 18 |
Type of covering | Door |
Cover model | With notch |
Transparent cover/door | Yes |
Housing material | Plastic |
Height | 400 mm |
Width | 400 mm |
Depth | 130 mm |
Inner depth | 48 mm |
Earthing terminal block | No |
Neutral terminal block | No |
DIN-rail | Yes |
With mounting plate | No |
Extension possible | Yes |
Colour | Grey |
RAL-number | 9016 |
Degree of protection (IP) | IP40 |
With lock | No |
Type of closure | Push button |
Signal passing door | No |
E-number Finland | 3466630 |
