Apparatus box AU3.32, brick wall apparatus box, HF
MOUNTING BOX AU3.32 BRICK WALL
ABB
Art.-no. WS1152367
EAN 6410011523674
With registration you can access the Würth Elektro online shop selection.
The device offers the AU3.2 apparatus box modified with a 28 mm deep extension ring. The box is suitable for a brick wall. No branch inlets are required at the bottom of the box. Straight access makes wire laying easier.
Datasheets(X)
Mounting method | Built-in |
Shape | Round |
Construction type | Device connection box (round/square) |
Model | Single |
Provided with revolving ring | No |
Couplable | Yes |
Equipped with | None |
For number of electric fittings | 1 |
Mounting switching equipment | Screwing |
With screws | Yes |
Housing feed-through by break-out opening | Yes |
Housing feed-through by seal membrane | No |
Housing feed-through by nozzle | No |
Housing feed-through by step membrane | No |
For tube diameter | 20/25 mm |
Pipe locking | Yes |
Pipe locking optional | No |
Inlet from the rear | Yes |
Number of inlets | 0 |
Number of included spouts | 0 |
Material | Plastic |
Halogen free | Yes |
Surface protection | Untreated |
Colour | White |
Degree of protection (IP) | Other |
Cover attachment | Snapped on |
Sealable | No |
Circuit integrity | None |
With screening | No |
Number of poles of the clamp | 0 |
Clamp position fixed | No |
Luminaire hook mounting | No |
Nozzle | None |
With nail lugs | Yes |
E-number Finland | 1152367 |
Brand | ABB |
