MULTIMET. LAMP PHILIPS CDM-T 70W/830 G12
With registration you can access the Würth Elektro online shop selection.
Datasheets(X)
 | |
Lamp power | 73.2 W |
Lamp voltage | 80-96 V |
Luminous flux | 6500 lm |
Socket | G12 |
UV protection | Yes |
Colour rendering index CRI | 80-89 |
Colour temperature | 3000 K |
Colour of light according to EN 12464-1 | Warm white <3300 K |
Lamp efficacy | 89 lm/W |
Lamp shape | U |
Material discharge tube | Ceramics |
Burning position | Random |
Diameter | 19 mm |
Total length | 100 mm |
External ignitor required | Yes |
External ballast required | Yes |
Closed luminaire required | Yes |
Sun tanning lamp | No |
Colour | White |
Colour of light | 830 |
Model | Clear |
Lamp designation | Other |
Energy efficiency class | G |
Weighted energy consumption in 1000 hours | 74 kWh |
Average nominal lifespan | 12000 h |
E-number Finland | 4824787 |
