Mushroom button Harmony - MUSHROOM HEAD ZB4BS844 RD HARMONY

Mushroom button Harmony - MUSHROOM HEAD ZB4BS844 RD HARMONY - 1

Mushroom button Harmony - MUSHROOM HEAD ZB4BS844 RD HARMONY - 2

Mushroom button Harmony - MUSHROOM HEAD ZB4BS844 RD HARMONY - 3

Mushroom button Harmony

Name: Mushroom button Harmony
Brand: SCHNEIDER ELECTRIC
SKU: WS2320586

MUSHROOM HEAD ZB4BS844 RD HARMONY
SCHNEIDER ELECTRIC

Art.-no. WS2320586

EAN 3389110888867

All versions

Similar products

Mushroom button Harmony

Art.-no. WS2320586

Quantity

x 1

Show availability at another Center

Exclusively for trade customers

With registration you can access the Würth Elektro online shop selection.

Locate Center shop
Login/Register
Call customer service: 010 308 4700

Your feedback for this product

Harmony mushroom buttons

Buttons available with spring return or with a bottom-fixed model

Button release methods: rotary release, key release or pull release

Several button sizes: 30, 40, 60 mm diameter

Product information

Würth Elektronik Oy Catalogue

Datasheets(X)

Certificates/ Documents


Colour button	Red/green
Construction type lens	Round
Diameter cap	40 mm
Hole diameter	22.5 mm
Degree of protection (IP)	IP66
Degree of protection (NEMA)	13
Type of button	High
Suitable for illumination	No
Switching function latching	Yes
Spring-return	No
With front ring	Yes
Material front ring	Metal
Colour front ring	Chrome
Suitable for emergency stop	Yes
Unlocking method	Turn-release
E-number Finland	2320586
Brand	SCHNEIDER ELECTRIC
