RCB 16A/230V 30mA WT GW95526
Art.-no. WS3202766
EAN 6438548134194
-
Show availability at another Center
In order to check the stock in a Würth Elektro branch, please log in.
If you have any questions, please call our service hotline at +358 10 308 4700.
Do you want to register as an Online Shop user? Please go to the registration page.
Exclusively for trade customers
With registration you can access the Würth Elektro online shop selection.
Product information
Datasheets(X)
 | |
Number of poles | 2 |
Rated voltage | 230 V |
Rated current | 16 A |
Rated fault current | 30 A |
Mounting method | Other |
Leakage current type | A |
Selective protection | No |
Short-time delayed tripping | No |
Voltage type | AC |
With interlocking device | No |
Frequency | 50/60 Hz |
Additional equipment possible | No |
Degree of protection (IP) | IP41 |
Built-in depth | 32 mm |
Ambient temperature during operating | -25-40 °C |
Explosion-proof | No |
E-number Finland | 3202766 |
