RELAY UNIT ON/OFF SPR-01
With registration you can access the Würth Elektro online shop selection.
Datasheets(X)
 | |
Bus system KNX | No |
Bus system KNX-RF (Radio Frequent) | No |
Bus system radio frequent | Yes |
Bus system LON | No |
Bus system Powernet | No |
Other bus systems | Other |
Radio frequent bidirectional | Yes |
Mounting method | Socket outlet |
Width in number of modular spacings | 1 |
Local operation/hand operation | Yes |
With LED indication | Yes |
Max. switching power | 3500 W |
Max. switching power LED | 800 W |
Output power | 3500 W |
Suitable for C-load | Yes |
Max. number of switching contacts | 1 |
Max. switching current | 16 A |
Rated current | 16 A |
Rated operating voltage | 220-240 V |
Different phases connectable | No |
With bus connection | Yes |
Bus module detachable | No |
Min. depth of built-in installation box | 38 mm |
Modular expandability | No |
Degree of protection (IP) | IP20 |
E-number Finland | 2618931 |
