SLEEVE SEAL VBS V-TEC LGR M50 IP68
Art.-no. WS1711150
EAN 4012195533900
-
Show availability at another Center
In order to check the stock in a Würth Elektro branch, please log in.
If you have any questions, please call our service hotline at +358 10 308 4700.
Do you want to register as an Online Shop user? Please go to the registration page.
Exclusively for trade customers
With registration you can access the Würth Elektro online shop selection.
Product information
Datasheets(X)
 | |
Thread type | Metric |
Nominal thread size metric/PG | 50 |
Pitch thread | 1.5 mm |
Thread length | 12 mm |
Wrench width | 54 mm |
Suitable for cable diameter | 23-35 mm |
Material | Plastic |
Material quality | Polyamide (PA) |
Surface protection | Untreated |
Halogen free | Yes |
Glass-fibre reinforced | No |
Degree of protection (IP) | IP68 |
Shock resistant | No |
Bend radius protection/trumpet flare | No |
With locknut | No |
Model | Straight |
Multi seal area | No |
Flat cable coupling | No |
With strain relief | Yes |
Type of sealing | Sealing ring |
Separable screw gland | No |
Operating temperature | -20-65 °C |
Explosion-tested version | No |
For Ex-zone gas | None |
For Ex-Zone dust | None |
E-number Finland | 1711150 |
