Number of control contacts

5

Contact insert without contacts

No

Contact type

Pin

Number of poles

5

Diameter plug-in contact

2.2 mm

Material connector insert

Thermoplastic

Rated current In

8 A

Ambient temperature

0-60 °C

Operating temperature

0-65 °C

Rated voltage

24 V

Rated surge voltage

2.5 kV

Overvoltage category

III

Pollution degree

2

Type of electric connection

Spring clamp connection

With wire protection

Yes

Connectable conductor cross section fine-strand without cable end sleeve

0.25-1.5 mm²

Connectable conductor cross section fine-strand with cable end sleeve

0.25-0.75 mm²

Connectable conductor cross section solid-core

0.5-1.5 mm²

Connectable conductor cross section multi-wired

0.5-1.5 mm²

Material contact

Nickel

Inflammability class of insulation material according to UL94

V0

With protective conductor

No

Min. number of insertion cycles

100

Width

19.54 mm

Height

7.8 mm

Depth

22.9 mm

E-number Finland

3447528

Brand

SCHNEIDER ELECTRIC
