Surface-mounted luminaire IP44 Start Eco Surface
START SURF. 12W 3K/4K 1025LM
SYLVANIA
Art.-no. WS4170569
EAN 5410288434261
With registration you can access the Würth Elektro online shop selection.
Start Eco Surface IP54 is a versatile and stylish surface-mounted wall and ceiling luminaire for indoor use that offers flexibility in lighting design. The colour temperature can be selected via a DIP switch to either 3000 K or 4000 K, which allows the lighting to be customized to different spaces and needs. Sturdy design with an opal acrylic cover.
Suitable for use in indoor areas of apartments, such as hallways, bathrooms and dressing rooms. Not suitable for stairwells. Durable frame IK03, splash-proof IP44.
Datasheets(X)
 | |
Suitable for suspended mounting | No |
Suitable for ceiling mounting | Yes |
Suitable for built-in mounting | No |
Suitable for surface mounting | Yes |
Suitable for light line configuration | No |
Lamp type | LED exchangeable |
With light source | Yes |
Suitable for number of light sources | 1 |
Housing material | Steel |
Surface protection housing | Powder coating |
Housing colour | White |
Material cover | Plastic, opal |
Type of grid | None |
Voltage type | AC |
Nominal voltage | 220-240 V |
Nominal current | 62.5-68.2 mA |
Type of control gear | LED operating device current-controlled |
With control gear | Yes |
Exchangeable control gear | No |
Dimming 0-10 V | No |
Dimming 1-10 V | No |
Dimming DALI-2 | No |
Dimming DALI | No |
Dimming DMX | No |
Dimming DSI | No |
Dimming potentiometer (integrated) | No |
Dimming manufacturer's proprietary system | No |
Dimming mains voltage modulation | No |
Dimming phase cut-off (trailing edge) | No |
Dimming phase cut-on (leading edge) | No |
Dimming programmable | No |
Dimming RF | No |
Dimming Touch and Dim | No |
Dimming Zigbee | No |
Dimming with push-button | No |
Light distributor | Diffuser lens/optic/panel |
Beam angle | Extreme wide beam >80° |
Colour consistency (McAdam ellipse) | SDCM6 |
Light outlet | Direct |
Rated lifetime L70/B50 at 25 °C | 90000 h |
Max. number of luminaires per miniature circuit breaker B16 (MCB) | 58 |
Max. number of luminaires per miniature circuit breaker C16 (MCB) | 96 |
Degree of protection (IP) | IP44 |
Impact strength | IK03 |
Protection class according to IEC 61140 | I |
Luminaire with limited surface temperature, sign "D" according to EN 60598-2-24 | No |
Rated ambient temperature according to IEC 62722-2-1 | -20-40 °C |
Suitable for emergency lighting | No |
With movement sensor | No |
With light sensor | No |
Covering of the luminaire with thermally insulating material possible | No |
With air slots | No |
Filament test according to IEC 60695-2-11 | 650 °C - 30 s |
Max. system power | 12 W |
Colour temperature | 3000-4000 K |
Colour rendering index CRI | 80-89 |
Power factor | 0.8 |
Constant light output (CLO) | No |
Width | 80 mm |
Height/depth | 80 mm |
Length | 80 mm |
Outer diameter | 250 mm |
Type of wiring | Ending |
Number of poles | 3 |
Conductor cross section | 2.5 mm² |
Connection type | Push-in clamp |
Photobiological safety according to EN 62471 | RG0 |
Colour of light adjustable | Continuously variable |
Luminous flux adjustable | No |
Beam angle adjustable | No |
Operation by Bluetooth | No |
Compatible with Apple HomeKit | No |
Compatible with Google Assistant | No |
Compatible with Amazon Alexa | No |
IFTTT support available | No |
E-number Finland | 4170569 |
Brand | SYLVANIA |
