Pendant control housing Harmony – XAC-A 2013
SUSPENSION CONTROL DEVICE 2-OPENINGS XAC
SCHNEIDER ELECTRIC
With registration you can access the Würth Elektro online shop selection.
Pendant controls for control circuits 2... 12 pcs Ø 22 mm pushbuttons
Functions: Movements up, down, right, left with one or two speeds: emergency stop option available
- Fulfil IEC standards
- CE marking
- UL/CS Certification
- IP 65
- Double insulated polypropylene case
- Screw terminals
- Perfectly suited products
- Products assembled by the customer which comprise of separate parts and joint equipment
Benefits: These sturdy pendant controls are designed for heavy use and fulfil the safety requirements of the IEC standards. They are simple and yet intuitive and very pleasant to use.
Applications:
- Industrial and service sectors: lifting applications, overhead cranes
Datasheets(X)
 | |
Number of command positions | 2 |
Housing material | Plastic |
Colour housing cover | Yellow |
Degree of protection (IP) | IP65 |
E-number Finland | 2319655 |
Brand | SCHNEIDER ELECTRIC |
