Conductor material

Copper

Conductor surface

Bare

Diameter conductor

1 mm

Conductor category

Class 1 = solid

Number of cores

6

Number of stranding elements

3

Stranding element

Pairs

Material core insulation

Polyolefin

Specification core insulation

Polyethylene (PE)

Core identification according to HD 308 S2

No

Core identification

Colour

Screen over stranding element

None

Stranding

Bundle

Screen over stranding

None

Longitudinal water blocking cable

Yes

Radial water blocking cable

Yes

Suitable for underground installation

Yes

Approved type of underground installation

Free-lying and underground installation tube

Protective sheath

Al/PE

Material outer sheath

Polyolefin

Specification material outer sheath

Polyethylene (PE)

Colour outer sheath

Black

Armouring/reinforcement

None

Cable geometry

Round

Reaction-to-fire according to EN 13501-6: Class

None

Reaction-to-fire according to EN 13501-6: Smoke production

None

Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

None

Reaction-to-fire according to EN 13501-6: Acidity

None

Halogen free according to EN IEC 60754-2

Yes

Low smoke according to EN IEC 61034-2

No

Oil resistant according to EN IEC 60811-404

No

Outer diameter approx.

14 mm

Min. permitted bending radius, stationary application/permanent installation

98 mm

Permitted cable outer temperature during assembling/handling

-20-60 °C

Permitted cable outer temperature after assembling without vibration

-45-70 °C

Category

3

NVP value

67 %

UV resistant

Yes

Certified for shipboard application

No

Suitable as telephone cable

Yes

Weight

190 kg/km

E-number Finland

0225056
