Thermostat ELKO One
Matter thermostat 16 A
THERMOSTAT MATTER 3680W WT ELKO ONE
SCHNEIDER ELECTRIC
Art.-no. WS2610206
EAN 7020160501073
With registration you can access the Würth Elektro online shop selection.
This modern smart thermostat works locally without the internet or cloud services, ensuring excellent security and user-friendliness. The device can be used and programmed directly from the menu – no need to register or install an application. The thermostat supports the Matter standard and is compatible with Amazon Alexa, Apple HomeKit, and Google Assistant. Smart home integration is easy with a Matter-compatible hub.
The modern design, translucent display and touch control make it comfortable to use. You can also adjust the temperature using voice commands, such as "Hey Google, set the living room temperature to 21 degrees".
Datasheets(X)
 | |
Regulation type on/off | Yes |
Regulation type modulating | Yes |
Communications protocol | Other |
Type of power supply | 230 V |
Connection | Wireless |
Measuring range | 4-30 °C |
External sensor | Yes |
With thermal feedback | Yes |
Control characteristic | PID |
Adaptive (self-learning) | No |
Suitable for heating | Yes |
Number of heater outputs | 1 |
Suitable for cooling | No |
Ventilation | No |
Adjustable differential | Yes |
Sensor/feeler type | Resistance sensor |
Temperature readable | Yes |
With display | Yes |
Type of clock | Week clock |
Clock model | Digital |
Overtime switch | No |
Optimisation | Yes |
With tap water circuit | No |
Operation | Touch screen |
Suitable for floor heating control | Yes |
Suitable for district heating control | No |
Remote operation possible | Yes |
IFTTT support available | No |
With presence perception | No |
Weather-dependent control system | Yes |
Number of switching programmes | 1 |
Contact type | Normally open contact (NO) |
Max. contact voltage | 230 V |
Max. contact load | 16 A |
Degree of protection (IP) | IP21 |
Colour | White |
RAL-number | 9003 |
Width | 75 mm |
Depth | 47 mm |
Height | 75 mm |
Class of the temperature control | II |
Standby power consumption (solstandby) | 0.5 W |
E-number Finland | 2610206 |
Brand | SCHNEIDER ELECTRIC |
