Mounting method

Wall surface mounted

Function

Escape route signage

Suitable for labelling type

Sticker

Type of indicator

Four-sided

With pictogram

Yes

Monitoring equipment

None

With remote switch connection

No

With remote control

No

Power supply system

Peripheral (individual battery)

Battery technology

Lithium-ion

Lamp type

Other

With light source

No

Lamp holder

None

Housing material

Plastic

Housing colour

Green

Material cover

Without cover

Voltage type

AC

Type of control gear

Not required

Exchangeable control gear

No

Light distributor

None

Rated lifetime L70/B50 at 25 °C

0 h

Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)

0 %

Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq)

0 %

Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)

0 %

Failure rate at median useful life of 100,000 h at 25 °C ambient (tq)

0 %

Constant light output (CLO)

No

Degree of protection (IP)

IP20

Degree of protection (NEMA)

1

Impact strength

IK00

Protection class according to IEC 61140

II

Luminaire with limited surface temperature, sign "D" according to EN 60598-2-24

No

Rated ambient temperature according to IEC 62722-2-1

5-45 °C

Max. system power

0 W

Rated luminous flux according to IEC 62722-2-1

0 lm

Luminous flux in standby mode

0 lm

Recognition distance

30 m

Nominal operation time

3-4 h

Width

158 mm

Height/depth

1 mm

Type of wiring

Ending

Conductor cross section

0 mm²

Connection type

Other

E-number Finland

7130002
