Connectable conductor cross section fine-strand without cable end sleeve

0.5-10 mm²

Connectable conductor cross section fine-strand with cable end sleeve

0.5-6 mm²

Connectable conductor cross section solid-core

0.5-10 mm²

Connectable conductor cross section multi-wired

0.5-10 mm²

Rated current In

41 A

Rated voltage

800 V

Type of electrical connection 1

Spring clamp connection

Type of electrical connection 2

Spring clamp connection

Number of levels

1

Number of clamp positions per level

4

Mounting method

DIN rail (top hat rail) 35 mm

Material insulation body

Thermoplastic

Operating temperature

-35-85 °C

Width

7.5 mm

Height

32.9 mm

Explosion-tested version 'Ex e'

Yes

Closing plate required

Yes

Colour

Grey

Internally connected stages

No

E-number Finland

1939589

Brand

WAGO
